Signal designation signs

Signal designation signs are provided for some signals and are fitted to either the signal post or to a wall near the signal.

FIGURE 38: Examples of outer home signal designation plates.

For further information please contact the Network Rules Unit on NRU@transport.nsw.gov.au — Download Expand

For further information please contact the Network Rules Unit on NRU@transport.nsw.gov.au — Download Expand

FIGURE 39: Examples of distant signal designation plates.

For further information please contact the Network Rules Unit on NRU@transport.nsw.gov.au — Download Expand

For further information please contact the Network Rules Unit on NRU@transport.nsw.gov.au — Download Expand

FIGURE 40: Examples of repeater signal designation plates.

For further information please contact the Network Rules Unit on NRU@transport.nsw.gov.au — Download Expand

For further information please contact the Network Rules Unit on NRU@transport.nsw.gov.au — Download Expand

For further information please contact the Network Rules Unit on NRU@transport.nsw.gov.au — Download Expand

FIGURE 41: Examples of indicator signal designation plates.

For further information please contact the Network Rules Unit on NRU@transport.nsw.gov.au — Download Expand

For further information please contact the Network Rules Unit on NRU@transport.nsw.gov.au — Download Expand

For further information please contact the Network Rules Unit on NRU@transport.nsw.gov.au — Download Expand

FIGURE 42: Examples of co-acting signal designation plates.

For further information please contact the Network Rules Unit on NRU@transport.nsw.gov.au — Download Expand
